Dri-Bar Parts List for the Dirt Modified Division
| PART DESCRIPTION | PART # | COST |
| Dirt Dri-Bar System | $975.00 | |
| 1.50" Frame Clamps | FR1500 | $72.88 |
| 1.75" Frame Clamps | FR1750 | $86.50 |
| 2.00" Frame Clamps | FR2000 | $86.50 |
| 1/4" Teflon Installation Screws 20 | T -SC | $0.43 |
| 1/4" Grease Zerk | 25 GZ | $5.37 |
| 44" X 12" Zink Coated Torsion Bar | TB 4400 - 120 | $196.99 |
| 45.75" X 12" Zink Coated Torsion Bar | TB 4575 - 120 | $196.99 |
| 44" X 13.75" Zink Coated Torsion Bar | TB 4400-135 | $196.99 |
| 45.75 X 13.5 Zink Coated Torsion Bar | TG 4575 -135 | $196.99 |
| Torsion Bar Clamps (Limits side travel) | 100 CL | $37.56 |
| 12.0" Adjustable Arm Base | BA - 2-01 | $64.80 |
| 13.5" Adjustable Arm Base | BA - 2-02 | $64.80 |
| .109 Dirt Dri-Bar Blade | BL1 - 6-109 | $89.50 |
| .125 Dirt Dri-Bar Blade | BL1-6-124 | $89.50 |
| .109 Dirt Dri-Bar Helper Blade | BL1 - 109 | $49.50 |
| Sliding Secondary | SD - 2 | $35.87 |
| Top Hats for Secondary Bolts | TP001 | $5.86 |
| Left Side Arm Cable Bracket | CB002L | $5.96 |
| Right Side Arm Cable Bracket | CB002R | $5.96 |
| Aluminum Arm Retention Washer | M001 | $4.99 |
| 8" Aluminum Drop Link (3.8" Thread) | M006-8000 | $15.75 |
| 8.75" Aluminum Drop Link (3.8" Thread) | M006-8750 | $15.95 |
| 10" Aluminum Drop Link (3.8" Thread) | M006-1000 | $16.45 |
| 10.75" Aluminum Drop Link (3.8" Thread) | M006-1075 | $16.75 |
| Right Hand 3/8" Drop Link Heim Joint | MM-6Y | $13.93 |
| Left Hand 3/8" Drop Link Heim Joint | MB-6Y | $14.20 |
| Right Hand 3/8" Jam Nut | JNR-6 | $0.51 |
| Left Hand 3/8" Jam Nut | JNL-6 | $1.46 |
| Control Unit (1.25" tubing) | CC1250 | $176.95 |
| Control Unit (1.375" tubing) | CC1375 | $176.95 |
| Control Unit (1.5" tubing) | CC1500 | $176.95 |
| Control Unit Cable Mount W/ Bracket (1.25") | CM1250 | $73.30 |
| Control Unit Cable Mount W/ Bracket (1.5") | CM1500 | $73.30 |
| Control Unit Cable Mount W/Bracket (1.75") | CM1750 | $73.30 |
| Control Cable 48" | CC48 | $59.40 |
| Control Cable 75" | CC75 | $59.40 |
| Control Cable 113" | CC113 | $59.40 |
| Female 10-32 Cable Heim Joints | MW3 | $9.48 |
| Complete System Bolt | $27.00 |
